Application: | Small Diameter Sewer Trenchless Repair | Component: | UV, Blower, Cable, Video, AC, Generator, Chassis |
---|---|---|---|
Cable Reel: | 160 Meters | Light: | LED |
Diameter: | DN200-600 | Material: | Stainless Steel |
Highlight: | DAO cured in place UV CIPP Equipments |
DAO UV cure system is in Integrated design, High integration!!! It is manufactured to repair underground small sewers, ranging from DN200 up to DN600.
Those features High efficiency and energy-saving, little pollution, and only a generator power supply.
The UV cable length is standard 160m, and more is available, the curing speed is 0.1 ~ 2.8m/min.
Digital transmission, real-time monitoring of repair status, automatic voltage stabilization.
Embedded industrial computer and keyboard, 15-inch touch screen, which can store high-definition images (1920 * 1080).
LED curing is adopted with a short curing time and high speed.
After the lining is cured, it is tensile, compressive, corrosion-resistant, and has independent structural strength.
The installation of D919 ultraviolet (UV) light curing integrated equipment is flexible. It can be installed on any chassis, or in containers, made into mobile and portable. The layout design in the vehicle is reasonable, which is convenient for on-site construction, and the supporting auxiliary supplies are complete, which can save the carrying of tool vehicles.
Small light train | |
Applicable pipe diameter | DN200-600 |
Light source | UV-LED cold light source, 400W * 6 two lamp strings |
Temperature sensor | Equipped with two temperature sensors (optical convenience 20:1, measurement accuracy ± 1%) |
Leg | The lamp legs suitable for DN250, dn400, DN500, and DN600 pipes can be interchanged as needed. |
Other features are available to order. |
